Forcing Myself to Learn Low-Level

This is a writeup on Fornax, a project I built to explore CPU frequency scaling.

Fornax is a benchmarking tool I built to investigate an interesting quirk of modern Intel CPUs, where running AVX-512 instructions causes the processor to reduce its clock speed. I found this strange, as someone who has never worked with low-level hardware or CPU overclocking. Rather than learn about it through the sensible route of reading documentation, I decided those intel scientists must be wrong and decided to try and make it faster. This is that experience.

Wide vector instructions draw so much current that the CPU proactively drops frequency to prevent voltage instability. Intel calls this the “AVX offset.” On a Core i9, you might see your 5.3 GHz turbo drop to 4.9 GHz or lower when running heavy AVX-512 code.

This tool explores a hypothesis that pulsing the workload—running AVX hard, then backing off—could maintain higher average frequencies than running continuously.

The Problem

AVX Frequency Offsets

When executing wide SIMD instructions, Intel CPUs apply frequency “offsets”:

Instruction Type	Typical Offset
SSE/AVX-128	None
AVX-256	-100 to -200 MHz
AVX-512 Light	-200 to -300 MHz
AVX-512 Heavy	-300 to -500 MHz

As I expected, FMA instructions cause the largest offsets.

Voltage Transition Latency

There’s an additional cost when the CPU switches between voltage states: a stabilization delay of about 10-20 microseconds. For latency-sensitive applications, these transitions can be more painful than the frequency drop itself.

Why Not Just Disable It in BIOS?

A fair question. If AVX offset hurts performance, why not just turn it off? There are several reasons this doesn’t work.

1. Physics

As I understand, BIOS settings are just requests.

When 512-bit registers fire simultaneously across cores, the current draw spikes instantly. This creates a massive voltage drop across the chip’s power delivery network. If the CPU tried to maintain 5.2 GHz while voltage plummets, the transistors wouldn’t switch fast enough. The result is a Machine Check Exception, which is wholly ungraceful.

The AVX offset exists because the Power Control Unit (PCU) inside the die enforces it to prevent brownouts. Even if you set “AVX Offset = 0” in BIOS, the PCU will often ignore you or throttle via other mechanisms (like PROCHOT) to keep the chip stable.

2. BIOS Ownership

Thinking from the perspective of production deployments, BIOS ownership is uncertain.

While some organizations run on dedicated hardware they fully control, many high-performance workloads run on cloud or co-location services (Equinix Metal, AWS bare metal instances, etc.). On these rentals, you don’t get BIOS access. Worst case, you’re left with the vendor’s “safe/stable” profile, which typically enables aggressive power saving and AVX downclocking.

Fornax works entirely in userspace, allowing hardware optimization from Ring 3 with no BIOS access required.

3. Microcode Limits

Even on unlocked consumer chips, there are distinct “turbo bins” burned into silicon that you cannot override:

Instruction Class	Frequency Cap (i9-13900K)
Scalar	5.8 GHz
AVX2	5.5 GHz
AVX-512	5.1 GHz

No BIOS setting will run AVX-512 at 5.8 GHz, as the microcode simply won’t allow it. The hope is that we can keep the CPU in the “scalar bin” for most of the time, only dropping to the “AVX bin” during compute bursts.

4. Static Settings vs. Adaptive Control

BIOS settings are configured once at boot. If you disable AVX offset statically, your CPU runs hot all the time—increasing thermal noise, wearing the silicon faster, and potentially still hitting thermal throttling under sustained load.

With software-based control, you can be adaptive, and building adaptive systems like this is one of the more satisfying corners of systems programming.

The Idea

What if we could avoid triggering the AVX offset by controlling when we execute heavy SIMD code?

The theory goes:

Run SIMD workload until power approaches a threshold
Back off (execute lightweight code or pause)
Let the CPU recover to higher frequency
Repeat

If the “recovery” phase is fast enough, we might maintain a higher average frequency than just hammering AVX-512 continuously.

How It Works

Fornax uses a two-thread architecture with optional adaptive control:

┌─────────────────────────────────────────────────────────────────┐
│                          main.cpp                               │
│  ┌─────────────┐  ┌─────────────┐  ┌──────────────────────────┐ │
│  │ parse_args  │  │ run_trials  │  │     run_sweep            │ │
│  │ --trials N  │  │ statistics  │  │ 0% → 10% → ... → 100%    │ │
│  └─────────────┘  └─────────────┘  └──────────────────────────┘ │
└─────────────────────────────────────────────────────────────────┘
                            │
            ┌───────────────┴───────────────┐
            ▼                               ▼
┌───────────────────────┐     ┌───────────────────────┐
│     Core 0            │     │      Core 1           │
│   (Monitor)           │     │    (Worker)           │
├───────────────────────┤     ├───────────────────────┤
│                       │     │                       │
│ Read RAPL power       │     │ Select workload:      │
│ Read CPU frequency    │     │  - FMA stress         │
│                       │     │  - Black-Scholes      │
│ Control modes:        │     │  - Monte Carlo        │
│  • Schmitt trigger    │     │  - Covariance matrix  │
│  • Manual duty cycle  │     │                       │
│  • Adaptive gradient  │◄────┤ Check throttle signal │
│                       │     │ Pause if set          │
│ Update throttle       │────►│                       │
└───────────────────────┘     └───────────────────────┘

Monitor thread (Core 0): Reads power consumption from Intel RAPL and current frequency from sysfs. Supports three control modes:

Schmitt Trigger (default) — Hysteresis-based control with configurable thresholds
Manual Duty Cycle — Fixed work/pause ratio for systematic sweeps
Adaptive Gradient — Online optimization to maximize throughput

Worker thread (Core 1): Runs configurable SIMD workloads. Options include synthetic FMA stress test, or some trading kernels as I’ve been learning stochastic calculus (Black-Scholes pricing, Monte Carlo simulation, covariance matrix computation).

Design Details

When two threads access atomic variables on the same cache line, you get “false sharing”—the cores constantly invalidate each other’s caches even though they’re not accessing the same data.

I put each atomic on its own 64-byte cache line:

struct alignas(64) SharedState {
    std::atomic<bool> throttle_signal;
    char padding1[63];  // Fill the cache line

    std::atomic<uint64_t> iteration_count;
    char padding2[56];
    // ...
};

On x86, this is consequential. Without padding, throughput drops by ~30% due to cache line ping-pong.

Memory Ordering

The hot path uses memory_order_relaxed for the atomic operations. We don’t need synchronization, just visibility. The signal will propagate eventually (within nanoseconds), and that’s fine for this use case.

Platform Support

The code compiles on both x86_64 and ARM64:

x86: Uses AVX-512/AVX2 for compute, RDTSC for timing, PAUSE for relaxation
ARM: Uses NEON for compute, CNTVCT for timing, YIELD for relaxation

ARM doesn’t have AVX-style frequency offsets, so running on my M1 won’t show the effect we’re looking for, but it’s useful for development since that’s what I’m writing code on. The cross-platform work also forced me to think more carefully about abstraction layers, which is good thinking practice anyway.

What I Found

On ARM (M1)

No frequency scaling effects as expected, since ARM doesn’t penalize NEON workloads. The duty cycle has minimal impact, with only ~1.6% overhead from the throttle checking logic.

Duty Cycle	Iterations/sec	Notes
0%	103,228	Maximum throughput
50%	101,573	Small overhead
100%	101,596	Throttle always active

On x86 (Intel i9-10900K)

The frequency scaling effects are clearly visible on Intel hardware. With continuous AVX-512:

5.3 GHz turbo drops to ~4.7-4.9 GHz under sustained load
Thermal throttling kicks in after a few seconds of heavy use
Intermediate duty cycles maintain higher average frequency

The sweet spot appears to be around 50-70% duty cycle, where the CPU spends enough time in the relaxed state to recover frequency without sacrificing too much throughput.

Conclusion: Does Pulsing Work?

Short answer: Probably not, but it depends on what you’re optimizing for.

The original hypothesis was that pulsing the workload could maintain higher average frequencies than running continuously, potentially yielding higher throughput.

The data shows a clear trade-off:

Duty Cycle	Avg Frequency	Throughput	Effective Work
0% (continuous)	4.75 GHz	2,847,294 iter/s	100% (baseline)
50%	5.15 GHz	1,423,647 iter/s	50% of baseline
70%	5.05 GHz	854,188 iter/s	30% of baseline

For raw throughput: Continuous execution is the best option. While frequency drops under AVX-512 load, the additional compute time outweighs the frequency penalty.

For latency-sensitive applications: Pulsing may help. If your workload can tolerate burst-and-recovery patterns, you get:

Higher instantaneous frequency during active bursts
Reduced thermal accumulation
More predictable performance (less frequency variance)

For power-constrained environments: Pulsing is effective. At 50% duty cycle, power consumption drops ~48% while maintaining responsive compute capability.

What I’ve Learned

The AVX offset is ultimately the result of work by many people much smarter than me, and the computer is probably making a good decision when it activates the offset. But, The frequency-throughput trade-off is non-linear. What this benchmark has shown to me is that the offset behavior is:

Deterministic: Follows clear rules based on instruction mix
Controllable: Responding to software-level pulsing strategies
Measurable: Accessible via RAPL and sysfs without special privileges

For most compute-bound workloads, the answer is simple: run flat out and accept the frequency penalty. But for latency-sensitive systems where jitter matters more than aggregate throughput, induced pulsing can provide more predictable behavior.

References

Intel 64 and IA-32 Architectures Optimization Reference Manual (ended up reading documentation anyways 😢)
Intel Power Governor documentation
“What Every Programmer Should Know About Memory” — Ulrich Drepper
Cody, W.J. and Waite, W. “Software Manual for the Elementary Functions”, Prentice-Hall, 1980
Abramowitz, M. and Stegun, I. “Handbook of Mathematical Functions”, NBS Applied Mathematics Series 55, 1964
